This is the Tamiya 58682A 1991 Audi V8 Touring (TT-02) RC Kit (No ESC)

Overview
This Tamiya R/C kit recreates the classic Audi DTM racing car as raced during the DTM 1991 season. The Audi V8 touring car had a 456hp 3.6-litre V8 which graced the DTM (Deutsche Tourenwagen Masters) racing series in Germany. In that season, it took four victories overall and carried Frank Biela to the drivers’ title.

Tamiya 1991 Audi V8 Touring Kit 1991 DTM Champion
This car graced the German Touring Car Championship (DTM) in 1991, with a 456hp 3.6-litre V8 engine mounted in the front and Audi's famed Quattro four-wheel drive. This model depicts the 4-door sedan body in polycarbonate with front and rear spoilers. With its imposing body, the Audi overcame significant ballast handicaps and stiff competition from the likes of BMW and Mercedes-Benz to bear driver Frank Biela to four wins and a superb Driver's Championship.

Depictions of headlights with polycarbonate light cases and stickers.
Design of small square side mirrors is specific to Audi.
Depictions of taillights with polycarbonate light cases.
Wheels use slick tyres with gold spokes and silver rims.

TT-02: Adaptable, balanced shaft driven 4WD
The shaft-driven 4WD TT-02 chassis employs a longitudinal layout with the battery on the left and the motor on the right to give excellent stability. Also, it features identical left and right suspension arms and uprights for ease of assembly, plus easy-to-maintain gearboxes. It is a highly adaptable chassis, as it offers 2 different wheelbases, 2 ground clearance settings and 2 tread set-ups in addition to a range of 10 possible gear ratios. It is not short on looks either, with brake disc-shaped wheel hubs and stylish front bumper supports. Wheels use slick tyres with gold spokes and silver rims.
Resin ball links in the steering linkage joints make for smooth, comfortable motion.
Wheel hubs are shaped to look like brake discs.
Motor cover includes removable cooling duct (not attached in above image).
This image gives a closer look at the rear double-wishbone suspension with friction dampers.

Features
1/10 R/C model assembly kit
Lightweight and durable polycarbonate body
Stickers are included to recreate the markings for the no.45 car driven by 1991 champion Frank Biela. Window masking stickers included to aid in the painting process
Two-piece mesh wheels (Item 50548 design) have silver colour rims and gold colour spokes. They are paired with racing slick tyres
4-bevel differential gears and 4-wheel double wishbone suspension make for smooth driving
Includes 540 Torque-Tuned motor

Specifications
Length: 463mm, Width: 188mm, Height: 138mm (18.2", 7.40", 5.43")
Wheelbase: 257mm (10.1")
Tyre Width/Diameter: 26/66mm (Front & Rear)
Front/Rear 4-Bevel Resin Differentials
3-Piece Steering Tie-Rod
Gear Ratio = 8.27:1 (9 further ratios from 11.38:1 to 7.28:1 possible with use of separately-sold pinion
Adjustable Gear Ratio: Yes
Bearings: Plastic bushing
Body Material: Polycarbonate
Body Stickers: Included
Chassis Type: TT-02
Construction Type: Assembly Kit
Differential Type: Gear
Drive Type: Shaft-Driven 4WD
Electronic Speed Control (ESC): Not Included
Motor: Brushed 540 Type
Scale: 1/10
Shock Damper: Friction type
Suspension: 4-wheel fully independent double wishbone
Terrain Use: On-Road

Included items
1/10 TT-02 1991 Audi V8 Touring Electric RC Car Kit

Required items (not included)
7.2V NiMH Battery & Compatible Charger
Standard Sized Servo
Electronic Speed Controller (ESC)
2Ch Transmitter & Receiver
Tamiya PS Paint

Please Note: This body shell comes completely UNPAINTED and may or may not require body post holes to be drilled. Only use a polycarbonate style paint such as The Tamiya PS series to finish these bodies as standard paints will not adhere and/or cause damage to the body shells surface.
